APlusLift HW-10KOH-A 10,000LB Asymmetric 2-Post Overhead Car Lift
APlusLift HW-10KOH-A 10,000LB Asymmetric 2-Post Overhead Car Lift APlusLift HW-10KOH-A 10,000LB Asymmetric 2-Post Overhead Car Lift APlusLift HW-10KOH-A 10,000LB Asymmetric 2-Post Overhead Car Lift APlusLift HW-10KOH-A 10,000LB Asymmetric 2-Post Overhead Car Lift APlusLift HW-10KOH-A 10,000LB Asymmetric 2-Post Overhead Car Lift

APlusLift HW-10KOH-A 10,000LB Asymmetric 2-Post Overhead Car Lift

Model: HW-10KOH-A
$2,549.00 $3,199.00

The HW-10KOH-A features asymmetric arm design with columns that rotate 30° to allow full door-open access to vehicle interiors. Same heavy-duty construction as the HW-10KOH with double-S column design, CE certified, and backed by a 3-year warranty.

Brand: APlusLift
Contact for Price & Install Call (612) 597-7615
Free Shipping Lower 48 states
Professional Install Available in our service area
Warranty 3 Years

Specifications

Lifting Capacity 10,000 lbs
Style Overhead Asymmetric
Overall Height 143 3/16"
Overall Width 134 5/16"
Max Lift Height (with adapters) 81"
Max Lift Height (without adapters) 75"
Drive Through Width 100"
Motor 220V Single Phase, 3HP, 10A
Rise Time 50 seconds
Concrete Requirement 6" thick at 3,500 psi reinforced
Shipping Weight 1,470 lbs

Features

✓ Asymmetric arm design for door-open access
✓ 30° column rotation
✓ CE Certified structure and hydraulic system
✓ Double point safety lock release
✓ Q355 steel carriage
✓ Dual hydraulic cylinders with chain drive
✓ Heavy-duty 3/8" diameter cable with 5" pulley
✓ Automatic arm lock restraints

What's Included

4 adjustable screw pads
4 pieces of 4" tall truck adapters
10 anchor bolts
10 shims
2 tool trays
2 toe guards
